Ford Performance 11″ Pressure Plate and Dowel Kit – M-6397-B46


Ford flywheel bolt and set down pin kit – 4.6 and 5.0 Coyote 11″

SKU: HMS-M-6397-B46



  • Six dowel pins total, three stepped .249/.315″ diameter, three 6.325mm diameter
  • Nine 10 mm X 1.5 pressure plate bolts for use with 11″ modular flywheel
  • Dowels are necessary to align and stiffen the pressure plate shell.
    • NOTE: If the dowels are not used the clutch may chatter and the engine may vibrate

For use with Ford Performance and production flywheels on 4.6L and 5.0L Coyote engines to align and attach the 11″ 6 or 9 bolt diaphragm-style pressure plate to the flywheel.

Increased clamp load over stock bolts on 1999-2010 applications.

Click here to see instructions for proper torque specs

NOTE: Does not include stepped dowels 6.635/7.04mm diameter or 7.944mm diameter dowels.

Additional information

Weight 1 lbs
Dimensions 3 × 2 × 2 in
