Lakewood Bellhousing 77-150 – 1958-1987 GM Small/Big block Chevrolet

$649.95

For GM standard pattern such as the Muncie, Saginaw, Borg Warner T10 & Tremec TKO transmissions. Fits GM full/midsized vehicles from ’58-’87.

In stock (can be backordered)

SKU: HMS-77-150

Description

Features:

  • Lakewood 77-150 Bellhousing
  • Designed For Mechanical Fork Linkage
  • Bellhousing Depth: 6.312 in
  • Clutch Fork Opening: 2.5 In X 3.75 In
  • Transmission Bore Diameter 4.684 In
  • Hydro formed Construction
  • Made In The USA
  • Works with 153 or 168 Flywheel
  • NON SFI Rated

Description:

The Lakewood 77-150 bellhousing connects small block and big block Chevy engines to transmissions utilizing the GM standard pattern such as the Muncie, Saginaw, Borg Warner T10 and Tremec TKO transmissions. This bellhousing is designed to fit GM full and midsized vehicles from ’58 – ’87.



Application: This bellhousing is not S.F.I. certified which is required by many sanctioning bodies for cars running 11.49 or faster in the quarter mile. The adapter bellhousing is an excellent choice for street rods, street machines, or truck applications where the use of a S.F.I. bellhousing is not necessary. This bellhousing does not include or accept an engine block plate.



Additional information

Weight 34 lbs
Dimensions 19 × 19 × 9 in
Manufacture

Lakewood Industries
